Brennan 1929-62-20-20 1929-62-20-20

BRENNAN 1929-62 Steel Port Block

BRENNAN 1929-62 Port Block, SAE Code 62 Flange X ORB, Steel

pin-int

BRENNAN Port Block, Series: 1929-62, Connection Type 1: SAE Code 62 Flange, Connection Size 1: 1-1/4 in, Thread Size 1: 1-5/8-12, Connection Type 2: ORB, Gender 2: Female, Connection Size 2: 1-1/4 in, Material Construction: Steel, 3-3/4 in Length, 3.06 in Width, 1-1/2 in Height

California residents see Prop 65 WARNINGS

Connection Size 1      :      1-1/4 in
Connection Size 2      :      1-1/4 in
Connection Type      :      Code 62~ORB
Connection Type 1      :      SAE Code 62 Flange
Connection Type 2      :      ORB
Fitting Type      :      Port Block
Gender 2      :      Female
Height      :      1-1/2 in
Industry Category      :      Hydraulic Flange Adapters & Accessories
Length      :      3-3/4 in
Material      :      Steel
Material Construction      :      Steel
Series      :      1929-62
Shape      :      Flange
Thread Size 1      :      1-5/8-12
Width      :      3.06 in
  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Brennan_1700-32-24_CAT.pdf
