Cato Western PMB254GLM D200-2504LM

Cato Western PMB254GLM

Cato Western PMB254GLM Black Enamel Dry Utility Pressure Gauge, 2-1/2 in Dial, 0 - 200 psi

  • Manufacturer: Cato Western
  • Brand: Cato Western
  • ARGPN: D200-2504LM
  • MPN: PMB254GLM
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Cato Western factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Cato Western Dry Utility Pressure Gauge, Series: PMB, Measuring System: psi, bar, Pressure Range: 0 - 200 psi, Connection Size: 1/4 in MPT, 2-1/2 in Dial Size, 3-2-3 % Accuracy, Analog Display, Bottom/Lower Mount, Steel Case, Lens Material: Acrylic, Finish: Black Enamel

Accuracy      :      3-2-3 %
Case Material      :      Steel
Connection Size      :      1/4 in MPT
Dial Size      :      2-1/2 in
Display Type      :      Analog
Finish      :      Black Enamel
Industry Category      :      Gauges
Lens Material      :      Acrylic
Measuring System      :      psi, bar
Mounting Type      :      Bottom/Lower
Pressure Range      :      0 - 200 psi
Product Type      :      Pressure Gauge
Series      :      PMB
  • In steam systems, a siphon should be installed between the gauge and the steam line
  • Gauge appearance may vary but your satisfaction is guaranteed
  • Brass/bronze tube, movement and connection
  • Dial is white
  • Brass internals and socket

Applications: For general service applications using air, water, oil and other media not corrosive to brass or bronze
