GatesĀ® C5E Black Synthetic Rubber High-Temp Flexline Hydraulic Hose, 13/32 in, 1250 psi
Click here
GatesĀ® High-Temp Flexline Hydraulic Hose, Series: C5E, Nominal Size: 13/32 in, 0.73 in OD, 13/32 in ID, 1250 psi, Material Construction: Synthetic Rubber, Synthetic Rubber Cover, Construction: 1-Braid of High-Tensile Steel Wire Over 1-Braid of Polyester, Black, 1.8 in Bend Radius, Resistance Properties: Heat, Oil, -40 deg F Low, 300 deg F High
| Attribute Type Configurator | : | Parent |
| Bend Radius | : | 1.8 in |
| Color | : | Black |
| Construction | : | 1-Braid of High-Tensile Steel Wire Over 1-Braid of Polyester |
| Cover Material | : | Synthetic Rubber |
| Inside Diameter | : | 13/32 in |
| Material | : | Nitrile |
| Material Construction | : | Synthetic Rubber |
| Nominal Size | : | 13/32 in |
| Outside Diameter | : | 0.73 in |
| Pressure Rating | : | 1250 psi |
| Product Type | : | Hydraulic Hose |
| Resistance Properties | : | Heat, Oil |
| Series | : | C5E |
| Temperature High | : | 300 deg F |
| Temperature Low | : | -40 deg F |
Applications: For air brake hose, power steering, engine and transmission coolant lines and hot lube oil lines
