Synflex® 37AL-03-250BX 37AL-03-250BX

Synflex® 37AL-03-250BX

Synflex® 37AL Orange Polyester Non-Conductive Aerial Lift Hose, 0.19 in, 1 ft L, 3000 psi

pin-int

Synflex® Non-Conductive Aerial Lift Hose, Series: 37AL, Nominal Size: 0.19 in, Dash Size: 03, 0.43 in OD, 0.19 in ID, 21 ft Length, 3000 psi, SAE Rating: SAE 100R7, Material Construction: Co-Polyester, Polyurethane Cover, Construction: Braided Synthetic Fiber, Orange, 0.4 in Bend Radius, -65 deg F Low, 212 deg F High

Attribute Type Configurator      :      Parent
Bend Radius      :      0.4 in
Color      :      Orange
Construction      :      Braided Synthetic Fiber
Cover Material      :      Polyurethane
Dash Size      :      03
Inside Diameter      :      0.19 in
Length      :      250 ft
Material      :      Polyester
Material Construction      :      Co-Polyester
Nominal Size      :      0.19 in
Outside Diameter      :      0.43 in
Pressure Rating      :      3000 psi
Product Type      :      Aerial Lift Hose
SAE Rating      :      SAE 100R7
Series      :      37AL
Temperature High      :      212 deg F
Temperature Low      :      -65 deg F
  • Low volumetric expansion - less than +/-2%

Applications: Electric utility truck, hydraulic systems, mobile equipment (pickers, utility vehicles)

  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Synflex_37AL-06-2-250BX_CAT.pdf
