Weatherhead® 10408N-688 10408N-688

Weatherhead® 104 N Zinc-Plated Carbon Steel Female 37 deg JIC Swivel 100R1 Field Attachable Reusable 45 deg Tube Elbow

Weatherhead® 104 N 100R1 Field Attachable Reusable 45 deg Tube Elbow, Hose X 37 deg JIC Swivel, Zinc-Plated, Carbon Steel

  • ARGPN: 10408N-688 loading
    • Connection Size 1:
    • Connection Size 2:
  • Add to cart
    Add To Favorites
    • pin-int

    Weatherhead® 100R1 Field Attachable Reusable 45 deg Tube Elbow, Series: 104 N, Connection Type 1: Hose, Gender 1: Female, Connection Size 1: 1/2 in, Hose Dash Size: 08, Connection Type 2: 37 deg JIC Swivel, Gender 2: Female, Connection Size 2: 1/2 in, Nominal Size: 1/2 in, Thread Size 2: 3/4-16, Hex Size: 1 x 7/8 in, Cut-Off Factor: 2.44 in, Material Construction: Carbon Steel, Finish: Zinc-Plated, For Use With: H104 Series Hoses, Dimensions: 4.08 in L x 1 in W x 1.48 in H, Dimension Standards: SAE 100R1

    Connection Size 1      :      1/2 in
    Connection Size 2      :      1/2 in
    Connection Type      :      Hose~JIC Female Swivel
    Connection Type 1      :      Hose
    Connection Type 2      :      37 deg JIC Swivel
    Cut-Off Factor      :      2.44 in
    Dimension Standards      :      SAE 100R1
    Finish      :      Zinc-Plated
    Fitting Type      :      45 deg Elbow
    For Use With      :      H104 Series Hoses
    Gender 2      :      Female
    Hex Size      :      1 x 7/8 in
    Hose Dash Size      :      08
    Material      :      Steel
    Material Construction      :      Carbon Steel
    Nominal Size      :      1/2 in
    Series      :      104 N
    Shape      :      45 deg Elbow
    Thread Size 2      :      3/4-16
    • Good selection of hose ends
    • Non-mandrel assembly

    Applications: Medium pressure hydraulic applications such as construction, farm implement and industrial equipment

    • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Aeroquip_06904D-604_CAT.pdf
