COXREELS® SLPF-650
COXREELS® SP-Fuel Series SLPF-650 Spring Driven Hose Reel, 50 ft Hose, 1 in ID x 1-1/2 in OD Dia Hose
- Manufacturer: Coxreels
- Brand: COXREELS®
- ARGPN: SLPF-650
- MPN: SLPF-650
-
Available for Pickup
- Anchorage, AK Branch:
Click here
-
Available for Shipping:
-
Available for Coxreels factory-direct delivery:
-
COXREELS® fuel dispensing reels are designed to handle various non-aromatic fuel applications including diesel, kerosene, fuel oil and heating oil. COXREELS® professional fuel dispensing reels are an essential component found in utility, ground support and bulk liquid handling transport services mounted on fuel storage and dispensing systems, fuel/lube trucks, aircraft refuelers and tank trucks. The convenient uncoiling systems with the added hose control allow the operator to efficiently handle fuel transfers.
COXREELS® Spring Driven Hose Reel, Series: SP-Fuel Series, 50 ft Hose, 1 in ID x 1-1/2 in OD Hose Dia, Low Pressure Hose, NPT Swivel Connection Type, Ratchet Locking Style, Steel, Powder-Coated, 300 psi, Base Mount, 26-3/8 in L x 19-5/8 in W x 24-1/2 in H, Additional Information: 25 in L x 15.38 in W Base, AFLAS Seal
| Additional Information | : | 25 in L x 15.38 in W Base, AFLAS Seal |
| Connection Type | : | NPT Swivel |
| Dimensions | : | 26-3/8 in L x 19-5/8 in W x 24-1/2 in H |
| Finish | : | Powder-Coated |
| Hose Capacity | : | 50 ft |
| Hose Diameter | : | 1 in ID x 1-1/2 in OD |
| Hose Type | : | Low Pressure |
| Locking Style | : | Ratchet |
| Material | : | Steel |
| Mounting Type | : | Base |
| Pressure Rating | : | 300 psi |
| Series | : | SP-Fuel Series |
- Professional grade heavy-duty steel construction
- Rolled edges and ribbed discs provide strength and safety
- Machined from zinc-plated steel 90 deg full flow NPT swivel for fuel dispensing applications
- Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance
- Heavy-duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety
- Sturdy box-style, reinforced steel frame design provides maximum strength and stability
- Heavy-duty 1 in stainless steel pinch-proof rollers
- Long-lasting, chip-resistant and rust inhibiting CPC™ powder-coat finish, adjustable solid rubber hose stop, fuel dispensing hose and sturdy permanently lubricated precision bearings
- Made in USA
