Danfoss Royalflex® H1196 Blue Nitrile Water Suction and Discharge Hose
Danfoss Royalflex® H1196 Blue Thermoplastic Vinyl Nitrile Water Suction and Discharge Hose, 2-1/2 in, 1 ft L, 300 psi
-
ARGPN: H119640-100
-
-
Available for Pickup
- Anchorage, AK Branch:
Click here
-
Available for Shipping:
-
Available for Danfoss Power Solutions factory-direct delivery:
Danfoss Royalflex® Water Suction and Discharge Hose, Series: H1196, Nominal Size: 2-1/2 in, Dash Size: 40, 3 in OD, 2-1/2 in ID, 1 ft Length, 300 psi, Material Construction: Thermoplastic Vinyl Nitrile, Thermoplastic Vinyl Nitrile Cover, Construction: 100% Polyester and Helical Wire, Blue, 10 in Bend Radius, Resistance Properties: Abrasion, Chemical, Heat, -20 deg F Low, 180 deg F High
| Attribute Type Configurator | : | Parent |
| Bend Radius | : | 10 in |
| Color | : | Blue |
| Construction | : | 100% Polyester and Helical Wire |
| Cover Material | : | Thermoplastic Vinyl Nitrile |
| Dash Size | : | 40 |
| Inside Diameter | : | 2-1/2 in |
| Length | : | 100 ft |
| Material | : | Nitrile |
| Material Construction | : | Thermoplastic Vinyl Nitrile |
| Nominal Size | : | 2-1/2 in |
| Outside Diameter | : | 3 in |
| Pressure Rating | : | 300 psi |
| Product Type | : | Suction and Discharge Hose |
| Resistance Properties | : | Abrasion, Chemical, Heat |
| Series | : | H1196 |
| Sub Brand | : | Royalflex® |
| Temperature High | : | 180 deg F |
| Temperature Low | : | -20 deg F |
- High-performance lightweight, kink-resistant suction and discharge hose for water applications
- Single homogeneous tube and cover
- Long length production capabilities
- High crush-resistant
- Easy-to-handle
- Economical, eliminates couplings
- Higher working pressure
- Lightweight and flexible
- Longer length
Applications: Transfer of water, liquid diluted fertilizers and pesticides, pumping, suction and discharge of water in petroleum industry oil and gas exploration, tank trucks, waste hauling and batch plant sand slurries
