Dixon® 300DD-90AL 300DD-90AL

Dixon® 300DD-90AL

Dixon® 300DD-90AL Aluminum Cam and Groove 90 deg Elbow, 3 in Female Type D

  • Manufacturer: Dixon Valve & Coupling Company, LLC
  • Brand: Dixon®
  • ARGPN: 300DD-90AL
  • MPN: 300DD-90AL
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Dixon Valve & Coupling Company, LLC factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Dixon® Cam and Groove 90 deg Elbow, Connection Type 1: Type D, Gender 1: Female, Connection Size 1: 3 in, Connection Type 2: Type D, Gender 2: Female, Connection Size 2: 3 in, 125 psi, Material Construction: Aluminum, Dimensions: 9-1/2 in L

California residents see Prop 65 WARNINGS

Connection Size 1      :      3 in
Connection Size 2      :      3 in
Connection Type 1      :      Type D
Connection Type 2      :      Type D
Dimensions      :      9-1/2 in L
Gender 1      :      Female
Gender 2      :      Female
Material      :      Aluminum
Material Construction      :      Aluminum
Pressure Rating      :      125 psi
Shape      :      90 deg Elbow
Produced as a welded fabricationBuna-N seal materialProduced to interchange with all product produced to commercial item description A-A-59326D356T6 aluminum constructionSafety Notes: Under no circumstances should cam and groove couplings be used for compressed air or steam service! Pressure rating recommendations are based on the use of mating Dixon® fittings at ambient temperature 70 deg F with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon®.Applications: For use with liquids
  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_100APM_CAT.pdf
  • Cut Sheet https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_150DA90AL_SS.pdf
  • Technical Drawing/Parts Diagram https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_300DD90AL_TD.pdf
