Dixon® 40MP-E100

Dixon® Standard Clamp Gasket, Connection Size 1: 1 in, 1.9 in ID, Material Construction: EPDM, Black, Dimensions: 1.98 in OD x 0.21 in THK

Color	:	Black
Connection Size 1	:	1 in
Dimensions	:	1.98 in OD x 0.21 in THK
Inside Diameter	:	1.9 in
Material	:	EPDM
Material Construction	:	EPDM
Shape	:	Gasket

Gasket material approved by (3A), USDA and complies with FDA's 21CFR177.2600 and 1550PSI service ratings for the sanitary clamps do not apply to connections (1 in and above) using any PTFE gaskets, due to the potential for cold flow under normal operating conditionsPTFE gaskets, when used with any clamp, are likely to leak at pressures far below the published service ratingsThis restriction does not apply to the fractionally sized 1/2 in and 3/4 in connections, due to their recessed, fully contained designPassed U.S.P. Class VI cytotoxicity testingPeroxide cured constructionStandards/Certifications: FDA 21 CFR 177.2600 Approved

• Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_40MP-XC150_Catalog.pdf
• Cut Sheet https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_40MP-E100_Cut_Sheet.pdf
• Technical Drawing/Parts Diagram https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_40MP-E100_Line_Drawing.pdf
