Dixon® AMH AMH

Dixon® AMH

Dixon® Air King™ AMH Iron 2-Lug Hose End, 3/8 in Hose

  • Manufacturer: Dixon Valve & Coupling Company, LLC
  • Brand: Dixon®
  • ARGPN: AMH
  • MPN: AMH
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Dixon Valve & Coupling Company, LLC factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Dixon® Air King™ 2-Lug Hose End, Connection Type 1: Hose, Connection Size 1: 3/8 in, 150 psi, Material Construction: Iron, Dimensions: 3-1/2 in L x 2-1/2 in W, For Use With: Air King™ Ferrules

California residents see Prop 65 WARNINGS

Connection Size 1      :      3/8 in
Connection Type 1      :      Hose
Dimensions      :      3-1/2 in L x 2-1/2 in W
For Use With      :      Air King™ Ferrules
Material      :      Malleable Iron
Material Construction      :      Iron
Pressure Rating      :      150 psi
Shape      :      Hose End
Sub Brand      :      Air King™
Safety clip includedSupplied with rubber washer AWR4Use of supplied safety clip guarantees the fittings are properly connected because the safety pin will not go through the holes in mating fittings until couplings are locked in placeOnly one Air King™ safety clip or wire-type retainer is required for each Air King™ universal couplingAir King™ meets pressure requirements as specified in A-A-59553 commercial item description superseding Mil Spec.WWC-633DApplications: For air and water service onlySafety Notes: Air King is for air and water service only.Never use any Air King coupling for steam service!The use of an Air King safety clip or wire-type retainer is necessary to ensure Air King universal couplings will not become accidentally disconnected.To provide protection against coupling breakage and related hazards, Dixon® recommends the use of a whip hose.Pressure rating given at ambient temperature 70 deg F.
  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_AM1_CAT.pdf
  • Cut Sheet https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_AM5_SS.pdf
  • Technical Drawing/Parts Diagram https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_AMH_TD.pdf
