DIXON 6HTBF8
DIXON Correct Connect™ HT Series 6HTBF8 Flushface Interchange Coupler, 3/4 in Quick Disconnect x 1 in Female BSPP, Steel
- Manufacturer: Dixon Valve & Coupling Company, LLC
- Brand: DIXON
- ARGPN: 6HTBF8
- MPN: 6HTBF8
-
Available for Pickup
- Anchorage, AK Branch:
Click here
-
Available for Shipping:
-
Available for Dixon Valve & Coupling Company, LLC factory-direct delivery:
-
DIXON Flushface Interchange Coupler, Series: HT, Fitting Type: Coupling, Connection Size 1: 3/4 in, Connection Type 1: Quick Disconnect, Connection Size 2: 1 in, Connection Type 2: Female BSPP, Material Construction: Steel, Chrome Trivalent-Plated, 1-11 Thread, 1-3/4 in Hex, 3.82 in L x 1.92 in OD
| Connection Size 1 | : | 3/4 in |
| Connection Size 2 | : | 1 in |
| Connection Type | : | Quick-Disconnect|Female BSP |
| Connection Type 1 | : | Quick Disconnect |
| Connection Type 2 | : | Female BSPP |
| Dimensions | : | 3.82 in L x 1.92 in OD |
| Finish | : | Chrome Trivalent-Plated |
| Fitting Type | : | Coupling |
| Hex Size | : | 1-3/4 in |
| Material | : | Steel |
| Material Construction | : | Steel |
| Series | : | HT |
| Thread Size | : | 1-11 |
| Thread Size 2 | : | 1-11 |
- High-flow performance, compact profile
- Easily re-buildable
- DORS (dual opposing retention spheres) retention system prevents valve stem ejection during surge flow and pressure spike conditions
- Machined components are manufactured using solid bar stock
- Stainless steel balls, retaining rings and spring maximize corrosion-resistant and extend service life
- Steel componentry is plated using RoHS compliant trivalent chrome
- Steel coupler sleeves are hardened to resist deformation and maximize service life
- Couplers have polyurethane valve stem O-ring, with a temperature range of -65 to 212 deg F
- Ancillary coupler seals are nitrile (Buna-N) with a temperature range of -40 to 250 deg F
- PTFE or TPC-ET anti-extrusion ring protects main coupling valve seal from dynamic impulse pressure damage
- Interchangeable to ISO16028
- Conforms to ISO16028 interchange standard interchangeable with Eaton/Hansen FF, Parker® FEM, Snap-Tite 74, Faster FFH/2FFN/2FFI, Stucchi A/FIRG and Holmbury HQ/A/FIMC
