Dixon® L300-A-SS

Dixon® Vent-Lock™ Safety Cam and Groove Adapter, Connection Type 1: Type A, Gender 1: Male, Connection Size 1: 3 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 3 in, Thread Size 2: 3-8, Hex Size: 3-3/4 in, 150 psi, Material Construction: 316 Stainless Steel, Dimensions: 2-29/32 in L, 70 deg F, For Use With: Ferrules, Sleeves, Bands and Other Reliable Attachment Options

California residents see Prop 65 WARNINGS

Connection Size 1	:	3 in
Connection Size 2	:	3 in
Connection Type 1	:	Type A
Connection Type 2	:	NPT
Dimensions	:	2-29/32 in L
For Use With	:	Ferrules, Sleeves, Bands and Other Reliable Attachment Options
Gender 1	:	Male
Gender 2	:	Female
Hex Size	:	3-3/4 in
Material	:	Stainless Steel
Material Construction	:	316 Stainless Steel
Pressure Rating	:	150 psi
Shape	:	Adapter
Sub Brand	:	Vent-Lock™
Temperature Rating	:	70 deg F
Thread Size 2	:	3-8

Safety release cam and groove couplings permit the release of static pressure when disconnecting hose assembliesVenting system protects operator from being sprayed with hazardous or non-hazardous fluids or solidsApplications: Transfer of fluids and solids, with a safe disconnectionSafety Notes: Pressure rating recommendation is based on the use of mating Vent-Lock™ L-style fittings at ambient temperature 70 deg F with standard Buna-N seal installed, for use at elevated temperature or other unusual operating conditions, consult Dixon®.Does not interchange with standard cam and groove products use only with Vent-Lock™ L-style fittings.

• Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_L300-A-SS_CAT.pdf
