Dixon® 8WF8-B 8WF8-B

Dixon® W Series Brass Quick Disconnect x FNPTF Wingstyle Interchange Coupler

Dixon® W Series Wingstyle Interchange Coupler, Quick Disconnect X NPTF, Brass

pin-int

Dixon® Wingstyle Interchange Coupler, Series: W, Connection Type 1: Quick Disconnect, Connection Size 1: 1 in, Connection Type 2: NPTF, Gender 2: Female, Connection Size 2: 1 in, Thread Size 2: 1 - 11-1/2, Hex Size: 1-15/32 in, 4000 psi, Material Construction: Brass, Dimensions: 4.49 in OD x 3.33 in L, -40 to 250 deg F

California residents see Prop 65 WARNINGS

Connection Size 1      :      1 in
Connection Size 2      :      1 in
Connection Type 1      :      Quick Disconnect
Connection Type 2      :      NPTF
Gender 2      :      Female
Hex Size      :      1-15/32 in
Industry Category      :      Hydrulic Quick Disconnects
Material      :      Brass
Material Construction      :      Brass
Pressure Rating      :      4000 psi
Series      :      W
Shape      :      Coupler
Thread Size 2      :      1 - 11-1/2
Full hex, ease-of-installationCompact body profile reduction of side-load stressHybrid valve guide for improved flow and pressure performanceAnti-extrusion seal-pack, superior longevityBonded flange valve for improved pressurized connection serviceMachined components are manufactured using solid bar stockStainless steel retaining rings and springs maximize corrosion resistance and extend service lifeSteel componentry is plated using RoHS compliant trivalent chromeRugged steel wing nut for threaded connect and disconnect operationNitrile (Buna-N) seals are standardMain coupler valve has a bonded face-seal to improve seal integrity during pressurized connection/disconnectionRedundant O-ring on the coupler body will engage nipple for secondary sealing supportCouplings have a TPC-EPT back-up ring on the valve sleeve to extend service lifeAeroquip 5100 Series, Parker 6100 SeriesSnap-Tite 78-Series, Faster Series-FB, Safeway S51-SeriesSafety Notes: Although wing style couplings are able to connect and disconnect while under pressure, it is recommended that hydraulic power supply be de-energized during connection to ensure operator safety.If it is not possible to de-energize the circuit, operators must be aware of their surroundings to ensure that an attachment or tool does not put them at risk, once hydraulic power is applied during the connection process.W-series couplings are not recommended for continuous hydraulic impulse applications at rated pressures.
  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_10WF10-B_CAT.pdf
