Dixon® W8F8-B W8F8-B

Dixon® W Series Brass Wingstyle Interchange Plug

Dixon® W Series Wingstyle Interchange Plug, Quick Disconnect X NPTF, Brass

pin-int

Dixon® Wingstyle Interchange Plug, Series: W, Connection Type 1: Quick Disconnect, Connection Size 1: 1 in, Connection Type 2: NPTF, Gender 2: Female, Connection Size 2: 1 in, Thread Size 2: 1-11-1/2, Hex Size: 1-9/16 in, 4000 psi, Material Construction: Brass, Dimensions: 2 in OD x 3.15 in L, -40 to 250 deg F

California residents see Prop 65 WARNINGS

Connection Size 1      :      1 in
Connection Size 2      :      1 in
Connection Type 1      :      Quick Disconnect
Connection Type 2      :      NPTF
Gender 2      :      Female
Hex Size      :      1-9/16 in
Industry Category      :      Hydrulic Quick Disconnects
Material      :      Brass
Material Construction      :      Brass
Pressure Rating      :      4000 psi
Series      :      W
Shape      :      Plug
Thread Size 2      :      1-11-1/2
Full hex, ease-of-installationVane valve guide for improved flow performanceCompact body profile reduction of side-load stressO-ring full-connection indicator for improved connection efficiencySwaged valve seal - resistance to flow damageMachined components are manufactured using solid steel and brass bar stockStainless steel retaining rings and springs maximize corrosion resistance and extend service lifeSteel componentry is plated using RoHS compliant trivalent chromeFor steel models, coupler valve sleeve and nipple valve are constructed of brassNitrile (Buna-N) seals are standard, providing a temperature range of -40 to 250 deg FCouplings have a TPC-ET back-up ring on the valve sleeve to extend service lifeNipple valve seal is crimped to improve seal integrity and prolong service lifeExternal O-ring on plug indicates full connection and acts as a contamination shield in connected modeRedundant O-ring on the coupler body will engage nipple for secondary sealing supportAeroquip 5100 Series, Parker 6100 Series, Snap-Tite 78-Series, Faster Series-FB, Safeway S51-SeriesApplications: For dump trailer wet-line hydraulic systems and oil field equipmentSafety Notes: Although wing style couplings are able to connect and disconnect while under pressure, it is recommended that hydraulic power supply be de-energized during connection to ensure operator safety.If it is not possible to de-energize the circuit, operators must be aware of their surroundings to ensure that an attachment or tool does not put them at risk, once hydraulic power is applied during the connection process.W-series couplings are not recommended for continuous hydraulic impulse applications at rated pressures.
  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_10WDP_CAT.pdf
