Dynamic Fluid Components CDS-4P-007D D100-1502CBM

Dynamic Fluid Components CDS-4P-007D

Dynamic Fluid Components CDS-4P-007D Dry Pressure Gauge, 1-1/2 in Dial, 0 - 100 psi

  • Manufacturer: Dynamic Fluid Components, Inc
  • Brand: Dynamic Fluid Components
  • ARGPN: D100-1502CBM
  • MPN: CDS-4P-007D
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Dynamic Fluid Components, Inc factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Dynamic Fluid Components Dry Pressure Gauge, Series: CDS, Measuring System: psi, bar, Pressure Range: 0 - 100 psi, Connection Size: 1/8 in MPT, 1-1/2 in Dial Size, +/-1.6% Full Scale Accuracy, -40 to 180 deg F, Analog Display, Center Back Mount, Steel Case, Lens Material: Polycarbonate, Dimensions: 1-1/2 in D

Accuracy      :      +/-1.6% Full Scale
Case Material      :      Steel
Connection Size      :      1/8 in MPT
Dial Size      :      1-1/2 in
Dimensions      :      1-1/2 in D
Display Type      :      Analog
Lens Material      :      Polycarbonate
Measuring System      :      psi, bar
Mounting Type      :      Center Back
Pressure Range      :      0 - 100 psi
Product Type      :      Pressure Gauge
Series      :      CDS
Temperature Rating      :      -40 to 180 deg F

CDS Series of dry gauges offer an accurate, inexpensive options for your pressure gauge needs. CDS gauges are constructed with a steel case, bronze bourdon tube and connection and polycarbonate lens. All of our gauges come with a built-in snubber. Standard gauge faces are designed with both psi and bar scales in a variety of ranges from vacuum to 6000 psi (5000 psi for 1-1/2 in ga). Certificates of Accuracy are available for an additional cost.

  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/DYNAMIC FLUID COMPONENTS_CDS-1P-070D_CAT.pdf
  • Cut sheet https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/DYNAMIC FLUID COMPONENTS_CDS-1P-070D_SS.pdf
