Gates® 4684-1561 4684CF150

Gates® Marine Master® Plus 4684CF Black Nitrile Wet Exhaust Hose

Gates® Marine Master® Plus Series 4684CF hoses are built for marine wet exhaust and coolant line applications requiring tight bends. Featuring a nitrile tube, synthetic fabric reinforcement with embedded helical wires, and a chloroprene cover, these hoses provide excellent heat, oil, and vacuum collapse resistance. Designed to handle pressures up to 100 psi and temperatures from -40°F to 212°F, the corrugated cover ensures flexibility and durability. Ideal for marine environments, this series is perfect for wet exhaust systems and general-purpose applications where performance and reliability are critical.

  • Add to cart
    Add To Favorites
    • pin-int

    Gates® Marine Master® Plus Wet Exhaust Hose, Series: 4684CF, Nominal Size: 1-1/2 in, 1.94 in OD, 1-1/2 in ID, 1 ft Length, 85 psi, Material Construction: Type C Nitrile, Chloroprene Cover, Construction: Synthetic Fabric with Built-In Wire, Black, 4 in Bend Radius, Resistance Properties: Heat, Oil, -40 deg F Low, 212 deg F High

    Bend Radius      :      4 in
    Color      :      Black
    Construction      :      Synthetic Fabric with Built-In Wire
    Cover Material      :      Chloroprene
    Inside Diameter      :      1-1/2 in
    Length      :      10 ft
    Material      :      Nitrile
    Material Construction      :      Type C Nitrile
    Nominal Size      :      1-1/2 in
    Outside Diameter      :      1.94 in
    Pressure Rating      :      85 psi
    Product Type      :      Exhaust Hose
    Resistance Properties      :      Heat, Oil
    Series      :      4684CF
    Sub Brand      :      Marine Master® Plus
    Temperature High      :      212 deg F
    Temperature Low      :      -40 deg F

    Marine wet exhaust and general-purpose applications. Suitable for coolant lines where tight bends are required. Wet exhaust hose with embedded helical wires and corrugated cover for tight bend radius, improved flexibility, kink and vacuum collapse resistance and fuel/oil resistance.

    • Nitrile tube, synthetic fabric reinforcement plies with two embedded helical wires, neoprene cover with wrapped appearance
    • Hose bead fitting fastened with hose clamps
    • Type A (chloroprene), black corrugated with red stripe cover

    Applications: For coolant hose or general-purpose applications

    • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Gates_46841551_CAT.pdf
    • Cut Sheet https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Gates_46841551_SS.pdf
    • Warranty PDF https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Gates_46841551_W.pdf
