Hansen™ and Gromelle™ FD69-1002-06-08 FD69-1002-06-08

Hansen™ and Gromelle™ FD69-1002-06-08

Hansen™ and Gromelle™ FD69 Zinc Trivalent-Plated Carbon Steel Water-Blast Ball Lock Coupling with Straight Thru Valve, 1/2 in Male Quick Disconnect x 3/8 in FNPT

  • Manufacturer: Danfoss Power Solutions
  • Brand: Hansen™ and Gromelle™
  • ARGPN: FD69-1002-06-08
  • MPN: FD69-1002-06-08
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Danfoss Power Solutions factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Hansen™ and Gromelle™ Water-Blast Ball Lock Coupling with Straight Thru Valve, Series: FD69, Connection Type 1: Quick Disconnect, Gender 1: Male, Connection Size 1: 1/2 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 3/8 in, Thread Size 2: 3/8-18, Hex Size: 1 in, 10000 psi, Material Construction: Carbon Steel, Finish: Zinc Trivalent-Plated, Dimensions: 1.85 in L x 1.64 in W x 1.64 in H, -4 to 212 deg F

Connection Size 1      :      1/2 in
Connection Size 2      :      3/8 in
Connection Type 1      :      Quick Disconnect
Connection Type 2      :      NPT
Dimensions      :      1.85 in L x 1.64 in W x 1.64 in H
Finish      :      Zinc Trivalent-Plated
Gender 1      :      Male
Gender 2      :      Female
Hex Size      :      1 in
Material      :      Steel
Material Construction      :      Carbon Steel
Pressure Rating      :      10000 psi
Series      :      FD69
Shape      :      Coupling
Temperature Rating      :      -4 to 212 deg F
Thread Size 2      :      3/8-18

Eaton FD69 Series design has a greater surface contact area for long service life in rugged high pressure and water blast applications. The maximum operating pressure is 10000 psi with 40000 psi minimum burst pressure.

  • Safety sleeve lock prevents accidental disconnection
  • Smooth bore straight through design for high-flow fluid requirements
  • Heavy-duty back-up ring prevents O-ring extrusion

Applications: High pressure water blast, bridge/concrete repair, paint stripping and shipyards

  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Hansen and Gromelle_FD90-1012-02-04_CAT.pdf
