Kingston Valves 292-2 292-2

Kingston Valves 292-2

Kingston Valves 292 Brass Low Flow Horizontal Side-Port Air Control Valve, 1/4 in NPT, 10 - 150 psi

  • Manufacturer: Strom Manufacturing Group
  • Brand: Kingston Valves
  • ARGPN: 292-2
  • MPN: 292-2
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Strom Manufacturing Group factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Kingston Valves Low Flow Horizontal Side-Port Air Control Valve, Series: 292, Nominal Size: 1/4 in, Connection Type: NPT, Material Construction: Brass, Brass Trim, Buna-N Seal, 2-3/16 in Height, 3-25/32 in Width, 10 - 150 psi

Connection Type      :      NPT
Height      :      2-3/16 in
Material      :      Brass
Material Construction      :      Brass
Nominal Size      :      1/4 in
Pressure Rating      :      10 - 150 psi
Product Type      :      Control Valve
Seal Material      :      Buna-N
Series      :      292
Trim Material      :      Brass
Width      :      3-25/32 in

Kingston Model 292-2 air control valve is a "two step" valve designed for operating single acting cylinders such as those found on lifting devices. It features durable brass construction with Buna-N seals. Inlet stem is designed to provide restricted flow on initial opening with full flow achieved when fully open.

  • Providing a second means to pressurize the cylinder by using a tire chuck without actuating the lever
  • Models 292-2 and 296-2 designs differ only in the position of the cylinder port
  • "Two-step" valve design for operating single acting cylinders
  • Horizontal side port
  • Cut sheet https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Kingston Valves_292-2_SS.pdf
