Landmann® Screw Pin Anchor Shackles
Landmann 1 in Screw Pin Anchor Shackle, Forged Carbon Steel, 17,000 lbs WLL.
-
ARGPN: SHACKLE 1
-
-
Load Capacity:
-
Load Capacity:
-
Available for Pickup
- Anchorage, AK Branch:
Click here
-
Available for Shipping:
-
Available for Landmann Wire Rope Products factory-direct delivery:
The Landmann 1 in Screw Pin Anchor Shackle features a forged carbon steel body with alloy steel pin, heat treated for strength and durability. Working Load Limit is 17,000 lbs (8-1/2 tons). Pin diameter is 1-1/8 in, inside width at pin is 1-11/16 in, and inside width at bow is 2-5/8 in. Approximate weight 5.25 lbs each. Hot dipped galvanized finish. Meets Federal Spec RR-C-271d, Type IV A, Grade A, Class 2. For use in rigging, lifting, and tie-down applications.
| Finish | : | Hot Dipped Galvanized |
| Inside Width | : | 1-11/16 in |
| Load Capacity | : | 17,000 lbs |
| Material | : | Forged Carbon Steel |
| Pin Diameter | : | 1-1/8 in |
| Pin Type | : | Alloy Steel |
| Product Type | : | Shackle |
