PT Coupling 40000230 MD20A

PT Coupling Maxi-Dry® Aluminum/EPDM MDA Maxi-Dry Adapter with Seal

PT Coupling Maxi-Dry® MDA Maxi-Dry Adapter with Seal, Fitting X NPT, Aluminum/EPDM

  • ARGPN: MD20A loading
    • Connection Size 1:
    • Connection Size 2:
  • Add to cart
    Add To Favorites
    • pin-int

    PT Coupling Maxi-Dry® MDA Maxi-Dry Adapter with Seal, Connection Type 1: Fitting, Connection Size 1: 2 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 2 in, 150 psi, Material Construction: Aluminum/Buna, Dimensions: 5.2 in L x 3.7 in W

    Connection Size 1      :      2 in
    Connection Size 2      :      2 in
    Connection Type 1      :      Fitting
    Connection Type 2      :      NPT
    Dimensions      :      5.2 in L x 3.7 in W
    Gender 2      :      Female
    Material      :      Aluminum
    Material Construction      :      Aluminum/Buna
    Pressure Rating      :      150 psi
    Shape      :      Adapter
    Sub Brand      :      Maxi-Dry®

    PT Coupling Maxi-Dry® dry-break adapters and couplers are built for long-term and rugged usage of liquid transfer applications. From water to paints, stains and solvents, to corrosive chemicals, the Maxi-Dry® is made for efficiency and safety with the dual purpose locking handle and internal stainless steel components.

    • Male and female cannot be disconnected while under pressure (helps maintain safe operations)
    • Coupler can be drained if necessary to minimize thermal expansion
    • Interchangeable with competitors
    • Made in USA
    • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/PT Coupling_5771009C_CAT.pdf
    • Cut sheet https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/PT Coupling_40000230_SS.pdf
    • Installation Instructions https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/PT Coupling_40001530_II.pdf
    • Technical Drawing/Parts Diagram https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/PT Coupling_40001530_TD.pdf

    Complete Your Assembly
