Weatherhead® 24708N-668 24708N-668

Weatherhead® 247 N Zinc Clear Trivalent Chromate Carbon Steel Female SAE 37 deg JIC Flare Swivel Field Attachable Reusable 90 deg Elbow

Weatherhead® 247 N Field Attachable Reusable 90 deg Elbow, Hose X SAE 37 deg JIC Flare Swivel, Zinc Clear Trivalent Chromate, Carbon Steel, 7000 psi

  • Add to cart
    Add To Favorites
    • pin-int

    Weatherhead® Field Attachable Reusable 90 deg Elbow, Series: 247 N, Connection Type 1: Hose, Connection Size 1: 13/32 in, Hose Dash Size: 08, Connection Type 2: SAE 37 deg JIC Flare Swivel, Gender 2: Female, Connection Size 2: 1/2 in, Nominal Size: 1/2 in, Thread Size 2: 3/4-16, Hex Size: 15/16 x 7/8 in, 7000 psi, Cut-Off Factor: 1.61 in, Material Construction: Carbon Steel, Finish: Dura-Kote, For Use With: H059, H069, H166, H169, H229, H366, and H569 Hoses, Dimensions: 2.76 in L x 0.875 in W x 1.09 in H, Dimension Standards: SAE 100R5

    Connection Size 1      :      13/32 in
    Connection Size 2      :      1/2 in
    Connection Type      :      Hose~JIC Female Swivel
    Connection Type 1      :      Hose
    Connection Type 2      :      SAE 37 deg JIC Flare Swivel
    Cut-Off Factor      :      1.61 in
    Dimension Standards      :      SAE 100R5
    Dimensions      :      2.76 in L x 0.875 in W x 1.09 in H
    Finish      :      Zinc Clear Trivalent Chromate
    Fitting Type      :      90 deg Elbow
    For Use With      :      H059, H069, H166, H169, H229, H366, and H569 Hoses
    Gender 2      :      Female
    Hex Size      :      15/16 x 7/8 in
    Material      :      Steel
    Material Construction      :      Carbon Steel
    Nominal Size      :      1/2 in
    Pressure Rating      :      7000 psi
    Series      :      247 N
    Shape      :      90 deg Elbow
    Thread Size 2      :      3/4-16
    • Very popular in heavy-duty truck markets
    • Good selection of hose ends
    • Compatible with a wide variety of hose-type allowing for a diverse number of applications
    • Non-mandrel assembly

    Applications: For a variety of applications including truck, industrial and small engine

    • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Weatherhead_24704N-B04_CAT.pdf
    • Technical Drawing/Parts Diagram https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Weatherhead_24704N-664_TD.pdf
