Weatherhead® by Danfoss 10Z-G69 10Z-G69

Weatherhead® by Danfoss 10Z-G69

Weatherhead® by DanfossZ Series Dura-Kote Carbon Steel Metric Split Flange Crimp Hose 45 deg Tube Elbow, 5/8 in

  • Manufacturer: Danfoss
  • Brand: Weatherhead® by Danfoss
  • ARGPN: 10Z-G69
  • MPN: 10Z-G69
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Danfoss factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Weatherhead® by DanfossCrimp Hose 45 deg Tube Elbow, Series: Z, Connection Type 1: Hose, Connection Size 1: 5/8 in, Hose Dash Size: 10, Connection Type 2: Metric Flange, Connection Size 2: 5/8 in, Cut-Off Factor: 2.23 in, Material Construction: Carbon Steel, Finish: Dura-Kote, For Use With: H104, H145, H145R, H190, H190H, H245, H245L, H280, H290, H290H, H290L, H345, H350, H400, H421, H425, H1777 (-04, -06, 08), H1776 (-04 thru -20), H1571 (-12 only), H6002 (-08, -12, -16), H6008 (-16 and -20), H6009 (-20 only), H9622 (-12, -16, -20), H265 (-04, -06, -08, -12, -16), H275 (-04 thru -16), H1812 (-04 thru -20), H0106 (-04 thru -10), H0105 (-06 thru -12, -20), H116 (-04, -06, -08), H115 (-04 thru -20), H1982 (-06 thru -16), H1981 (-04, -06, -08), H9949, EC115, EC215, EC110, EC210, and EC118 Series Hoses, Dimensions: 3.39 in L x 1.39 in W x 0.86 in H, Dimension Standards: SAE J1176

Connection Size 1      :      5/8 in
Connection Size 2      :      5/8 in
Connection Type      :      Hose~Komatsu Flange
Connection Type 1      :      Hose
Connection Type 2      :      Metric Flange
Cut-Off Factor      :      2.23 in
Dimension Standards      :      SAE J1176
Dimensions      :      3.39 in L x 1.39 in W x 0.86 in H
Finish      :      Dura-Kote
Fitting Type      :      45 deg Elbow
For Use With      :      H104, H145, H145R, H190, H190H, H245, H245L, H280, H290, H290H, H290L, H345, H350, H400, H421, H425, H1777 (-04, -06, 08), H1776 (-04 thru -20), H1571 (-12 only), H6002 (-08, -12, -16), H6008 (-16 and -20), H6009 (-20 only), H9622 (-12, -16, -20), H265 (-04, -06, -08, -12, -16), H275 (-04 thru -16), H1812 (-04 thru -20), H0106 (-04 thru -10), H0105 (-06 thru -12, -20), H116 (-04, -06, -08), H115 (-04 thru -20), H1982 (-06 thru -16), H1981 (-04, -06, -08), H9949, EC115, EC215, EC110, EC210, and EC118 Series Hoses
Hose Dash Size      :      10
Material      :      Steel
Material Construction      :      Carbon Steel
Series      :      Z
Shape      :      45 deg Elbow
  • Dura-Kote™ plating for superior corrosion resistance
  • Innovative design to deliver performance and maximum uptime
  • System engineered to extend hose assembly life

Applications: General-purpose low and medium-pressure hydraulics

  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Weatherhead_04Z-10E_CAT.pdf
