Gates® 3658-1977 10C5M

Gates® Type C Nitrile Hydraulic Marine Fuel Line Hose

Gates® Hydraulic Marine Fuel Line Hose, Black, Type C Nitrile

pin-int

Gates® Hydraulic Marine Fuel Line Hose, Series: 10C5M, Nominal Size: 1/2 in, 0.92 in OD, 1/2 in ID, 3 ft Length, 500 psi, Material Construction: Type C Nitrile, Type C2 Nitrile Cover, Construction: Braided, Black, 2.3 in Bend Radius, Resistance Properties: Flame, High Oil, -4 deg F Low, 212 deg F High

Attribute Type Configurator      :      Parent
Bend Radius      :      2.3 in
Color      :      Black
Construction      :      Braided
Cover Material      :      Type C2 Nitrile
Inside Diameter      :      1/2 in
Length      :      3 ft
Material      :      Nitrile
Material Construction      :      Type C Nitrile
Nominal Size      :      1/2 in
Outside Diameter      :      0.92 in
Pressure Rating      :      500 psi
Product Type      :      Fuel Line Hose
Resistance Properties      :      Flame, High Oil
Series      :      10C5M
Temperature High      :      212 deg F
Temperature Low      :      -4 deg F
  • One-wire braid reinforcement
  • Braided, high-tensile steel wire
  • 4:1 design factor

Applications: For all commercial, recreational vessel fuel line, B100 biodiesel, gasohol fuels, on-shore/off-shore, marine diesel fuel, gasoline and hot oil lines applications
