Hansen™ and Gromelle™ 3SD11 3SD11

Hansen™ and Gromelle™ 3SD11

Hansen™ and Gromelle™ 3000 Brass Coupling, 1/4 in Female Quick Disconnect x 3/8 in ID and 3/4 in OD Hose

  • Manufacturer: Danfoss Power Solutions
  • Brand: Hansen™ and Gromelle™
  • ARGPN: 3SD11
  • MPN: 3SD11
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for Danfoss Power Solutions factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

Hansen™ and Gromelle™ Coupling, Series: 3000, Connection Type 1: Quick Disconnect, Gender 1: Female, Connection Size 1: 1/4 in, Connection Type 2: Hose, Connection Size 2: 3/8 in ID x 3/4 in OD, Hex Size: 0.88 in, 2000 psi, Material Construction: Brass, Dimensions: 2.84 in L x 1.19 in W x 1.19 in H, Dimension Standards: ISO 6150 Series B, -40 to 250 deg F

Connection Size 1      :      1/4 in
Connection Size 2      :      3/8 in ID x 3/4 in OD
Connection Type 1      :      Quick Disconnect
Connection Type 2      :      Hose
Dimension Standards      :      ISO 6150 Series B
Dimensions      :      2.84 in L x 1.19 in W x 1.19 in H
Gender 1      :      Female
Hex Size      :      0.88 in
Material      :      Brass
Material Construction      :      Brass
Pressure Rating      :      2000 psi
Series      :      3000
Shape      :      Coupling
Temperature Rating      :      -40 to 250 deg F
Danfoss's 3000 Series industrial interchange pin lock pneumatic quick disconnect couplings are designed for compressed air, gases, and liquids. This series sets the industry standard for pin lock style pneumatic couplings. Easy, automatic, push-to-connect design provides instantaneous connection and disconnection of lines, plus automatic shut-off of socket/female end of line All sizes accept US industrial interchange, 1/4 and 1/2 in also accept ISO 6150 Series B and A-A-59439 plugs/males Buna-N seal material Applications: Industrial breathing air, general pneumatics, maintenance and repair, fluid transfer
  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Hansen and Gromelle_100006E_CAT.pdf
