ZSI-Foster BL50FSS FOS BL50SS

ZSI-Foster BL50FSS

ZSI-Foster FST 303 Stainless Steel Straight-Thru Ball Lock Coupling, 1/2 in Female Quick Disconnect x 1/2 in FNPT

  • Manufacturer: ZSI-Foster
  • Brand: ZSI-Foster
  • ARGPN: FOS BL50SS
  • MPN: BL50FSS
  • ARG Industrial Available for Pickup - Anchorage, AK Branch: loading Click here
  • ARG Industrial Available for Shipping: loading
  • Available for ZSI-Foster factory-direct delivery: loading
  • loading
  • Add to cart
    Add To Favorites
pin-int

ZSI-Foster Straight-Thru Ball Lock Coupling, Series: FST, Connection Type 1: Quick Disconnect, Gender 1: Female, Connection Size 1: 1/2 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 1/2 in, Thread Size 2: 1/2-14, 6700 psig, Material Construction: 303 Stainless Steel, -40 to 250 deg F

California residents see Prop 65 WARNINGS

Connection Size 1      :      1/2 in
Connection Size 2      :      1/2 in
Connection Type 1      :      Quick Disconnect
Connection Type 2      :      NPT
Gender 1      :      Female
Gender 2      :      Female
Material      :      Stainless Steel
Material Construction      :      303 Stainless Steel
Pressure Rating      :      6700 psig
Series      :      FST
Shape      :      Coupling
Temperature Rating      :      -40 to 250 deg F
Thread Size 2      :      1/2-14
  • FST straight-thru, no valve in either socket or plug
  • Standard industrial interchange design, most widely used in industry, within each series, only sockets and plugs of the same size will couple together
  • Socket sleeve must be manually retracted to connect and disconnect
  • Ball lock locks socket against accidental disconnect, to connect, align ball with slot, after connection, rotate sleeve to lock, to disconnect, realign ball with slot and retract sleeve
  • Buna-N standard seal
  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/ZSI-Foster_2702_CAT.pdf
