Aeroquip® by Danfoss FC195-04 FC195-04

Aeroquip® by Danfoss FC195-04

Aeroquip® by Danfoss FC195-04 Blue Elastomer High Impulse 2-Wire Braided Hose, 1/4 in, 5000 psi

pin-int

Aeroquip® by Danfoss High Impulse 2-Wire Braided Hose, Nominal Size: 1/4 in, 0.69 in OD, 1/4 in ID, 5000 psi, SAE Rating: SAE 100R2AT, Material Construction: Elastomer, Elastomer Cover, Construction: Braided, Blue, 4 in Bend Radius, Resistance Properties: Fire, Petroleum, -40 deg F Low, 302 deg F High

Attribute Type Configurator      :      Parent
Bend Radius      :      4 in
Color      :      Blue
Construction      :      Braided
Cover Material      :      Elastomer
Inside Diameter      :      1/4 in
Material      :      Elastomer
Material Construction      :      Elastomer
Nominal Size      :      1/4 in
Outside Diameter      :      0.69 in
Pressure Rating      :      5000 psi
Product Type      :      Braided Hose
Resistance Properties      :      Fire, Petroleum
SAE Rating      :      SAE 100R2AT
Temperature High      :      302 deg F
Temperature Low      :      -40 deg F

Applications: For petroleum and fire-resistant hydraulic fluids, fuel and lubricating systems

  • Catalog https://www.teamarg.com//ASSETS/DOCUMENTS/ITEMS/EN/Aeroquip_FC195-04_CAT.pdf
